20kg Metal Gear Servo – CCW Rotation, Optimized for Viper Lifters & Super Scoopers

Description

Replacement Servo for the Viper Lifter Add-On.

Input: 4.8V – 10.0V If your robot’s battery is higher than 9V, simply run the servo power from a 9V regulator.

Specifications:

• Range of Motion: 270° on a full 500-2500 PWM range.  On a standard robot remote you’ll have closer to 1000-2000 and achieve a real life travel of about 120°.
• Rotation: Counter Clockwise
• Dimensions: 40mm x 40mm x 20mm (1.57″ x 1.57″ x 0.79″) Weight: 62g (2.19oz)
• Construction: All metal gears, double ball bearing
• Accepts 25T Futaba-splined servo arms.

Performance Info:

• 9.0V
• Speed: 0.1 sec/60 degrees
• Stall Torque: 35kg-cm
• 7.4V (2s)
• Speed: 0.15 sec/60 degrees
• Stall Torque: 30kg-cm
• 6.0V
• Speed: 0.2 sec/60 degrees
• Stall Torque: 22kg-cm
